Inner Steel & Outer Aluminum Partitions
Combining the unmatched strength of steel with the sleek finish of aluminum, this system offers structural integrity, modern aesthetics, and excellent versatility. Perfect for spaces demanding both durability and design freedom, such as corporate offices, educational institutions, and government buildings.
Why Choose Our Inner Steel & Outer Aluminum Series?
Dual-Material Advantage
Steel inside ensures load-bearing strength and stability; aluminum exterior provides a refined, corrosion-resistant finish ideal for modern interiors.
Superior Acoustic Control
This hybrid system allows for enhanced insulation, minimizing noise transfer between rooms for quieter, more focused work environments.
Customizable Design Solutions
Adaptable to various layouts with options for framed, semi-framed, and frameless appearances—ideal for both open and private space division.
Design Options
| Category | Details |
|---|---|
| Matching Door Series | Pure Glass Door, Eco-Wood Door, Aluminum-Framed Glass Door, Floor Spring Door |
| Door Sizes | Single Door: W900mm × H3000mm × T40-45mm Double Door: W1600mm × H3000mm × T40-45mm |
| Height Options | Standard height: Up to 3000mm Extended height: Up to 4500mm with reinforced steel frame |
| Panel Width Options | Full Height: 900mm–1200mm Multi-section with transom bar: up to 1500mm–2000mm |
| Frame Material | 6063-T5 Aluminum Alloy exterior, Cold-rolled composite galvanized steel core, 45-degree miter joint assembly, no exposed screws |
| Frame Structure | Tempered glass with polished edges, Eco-surface panels, Steel laminated panels |
| Skirting Options | Available in 20mm–100mm height |
| Glass Thickness | 5mm, 6mm, 8mm, 10mm, 12mm tempered glass options |
| Panel Thickness | Panel Thickness |
| Acoustic Performance | Sound insulation up to ≤ 42dB |
Right-Angle Snap-Fit Structure
45-Degree Miter Joint Structure
Easy Installation & Trusted Performance
Experience smooth installation and reliable performance specifically designed for demanding office and commercial environments. The inner steel frame offers strength and stability, while the outer aluminum finish ensures precise alignment and ease of handling on site.
Quick Assembly
Low Maintenance
- Inner steel framework for superior load-bearing capacity and structural reliability
- Precision aluminum exterior for seamless aesthetics and corrosion resistance
- Designed for frequent reconfiguration and relocation without compromising integrity
FAQs
The steel core provides exceptional stability while the aluminum exterior ensures lightweight handling and design flexibility.
Yes, various anodized and powder-coated finishes are available, including custom RAL colors.
Yes, it offers superior sound insulation compared to single-material systems.
Absolutely, its modular design allows for multiple reconfigurations without damage.
While our system is designed for straightforward modular assembly, professional installation is advised for optimal fit, structural integrity, and finish quality, especially in complex or large-scale projects.
Request Customization or Quotation
Looking for a door solution perfectly tailored to your space? Our design team is ready to assist you with technical drawings, samples, and pricing.
